Cross Linked Insulation Flame Retardant Power Cable of Rated Voltage 8.7/10kV or Lower for Coal Mine Application
Http://www.ahzdh.com Time: 11/04/10 15:01Executive standard:
MT818.13-1999 “ Copper core fixed installation flame retardant power cable of rated voltage 10kV or lower for coal mine application---part 3 XLPE insulation power cable for coal mine application”
Working Condition
- Max. working temperature of cable conductor is 90℃
- Max. temperature of cable conductor is no more than 250℃ during shirt circuit. (The longest lasting time is no more than 5 seconds.)
- Cable installation temperature is no less than 0℃.
Cable type & name
Type |
Name |
MYJV |
Copper core XLPE insulation PVC sheath power cable for coal mine application |
MYJV22 |
Copper core XLPE insulation steel tape armoring PVC sheath power cable for coal mine application |
MYJV23 |
Copper core XLPE insulation thin steel wire armoring PVC sheath power cable for coal mine application |
MYJV42 |
Copper core XLPE insulation thick steel wire armoring PVC sheath power cable for coal mine application |
